High-Frequency Hybrid Pressing PCB: Rogers RO4350B｜6-Layer Immersion Gold with Impedance Control & Resin Plug Hole
High-frequency Hybrid pressing PCB |impedance | resin plug hole
| Type | High-frequency Hybrid pressing PCB |impedance | resin plug hole |
| Materia | Rogers RO4350B + Regular Substrates S1000-2M、FR-4、TG170 |
| Number of layer | 6L |
| Board Thickness | 2.0mm |
| Single size | 153.27*129mm/1PCS |
| Surface finish | ENEPIG |
| Inner copper thickness | 35um |
| Outer copper thickness | 35um |
| Color of solder mask | green(GTS，GBS) |
| Silkscreen color |
white(GTO,GBO) |
| Via treatment | resin plug hole |
| Density of mechanical drilling hole | 11W/㎡ |
| Density of laser drilling hole | / |
| Min via size | 0.3mm |
| Min line width/space | 8/8mil |
| Aperture ratio | 7mil |
| Pressing times | 1time |
| Drilling times | 1time |
| PN | B0690662A |
What is High-Frequency Hybrid Pressing PCB?
2.Impedance Control
oPrecise impedance control is achieved through advanced design and manufacturing techniques, ensuring signal integrity in high-speed and high-frequency applications.
3.Resin Plug Hole Technology
oResin plug holes enhance the reliability of the PCB by preventing air gaps and improving thermal conductivity. This technology is particularly beneficial for high-power and high-frequency applications.
4.6-Layer Immersion Gold Design
oThe 6-layer stack-up provides optimal signal routing and power distribution, while immersion gold surface finish ensures excellent solderability and corrosion resistance.
Why Choose Us as Your High-Frequency PCB Manufacturer?
High-Frequency Hybrid Pressing PCB FAQ
Applications of High-Frequency Hybrid Pressing PCB
6.Industrial IoT (IIoT) Systems
Our PCBs support high-speed data transmission and real-time monitoring, enhancing efficiency in smart factories and industrial automation.
7.Military Communication Systems
Designed for harsh environments, these PCBs ensure secure and reliable communication in military operations.
8.Drone Communication Modules
Our PCBs enable stable and real-time data transmission for drone control and telemetry, essential for both commercial and military drones.
9.Test and Measurement Equipment
These PCBs are used in high-frequency signal analyzers and network analyzers, providing accurate measurements for R&D and quality assurance.
10.Consumer Electronics
In high-end routers, gaming consoles, and smartphones, our PCBs support high-speed data processing and seamless connectivity.
11.Autonomous Driving Systems
Our PCBs are integral to the sensors and control units of autonomous vehicles, ensuring precise data processing and decision-making.
12.Smart Traffic Systems
Used in vehicle recognition and traffic flow monitoring, these PCBs enhance the efficiency and safety of urban transportation networks.
Unlock the Potential of High-Frequency Hybrid Pressing PCBs
Whether you're developing cutting-edge 5G infrastructure, advanced automotive systems, or mission-critical aerospace equipment, our high-frequency hybrid pressing PCBs are designed to meet your most demanding requirements. With a focus on innovation, quality, and customer satisfaction, we are committed to delivering solutions that drive your success. Contact us today to learn more about how we can support your next project!
